Seasonic CORE GX-850 - 850W 80 PLUS Gold Fully Modular ATX 3.1 PCIe 5.1 PSU
850W 80 PLUS Gold fully modular ATX 3.1 & PCIe 5.1 PSU with 1x 12V-2×6 + 3x 6+2-pin PCIe, 120mm HDB fan, braided cables, OptiSink tech & 7-year warranty. Compact 140mm depth for easy builds.
Доступно через 4–6 рабочих дней : 2 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Seasonic CORE GX-850 ATX 3.1 complies with latest standards, delivering 850W with 80 PLUS Gold efficiency (up to 93% peak). Fully modular black braided cables simplify builds in tight spaces. Features 120mm Hydro Dynamic Bearing fan with Smart & Silent control for optimal cooling and low noise.
ATX 3.1 / PCIe 5.1 ready with 1x 12V-2×6 (600W) connector for modern GPUs like RTX 5080 plus 3x 6+2-pin PCIe. Single +12V rail (70A/840W), OptiSink design improves heat dissipation 8x via optimized PCB layout. Premium Japanese capacitors ensure reliability; backed by 7-year warranty.
- ✅ 80 PLUS Gold certified (91-93% efficiency)
- ✅ Fully modular w/ braided cables
- ✅ 1x 12V-2×6 + 3x PCIe 6+2-pin
- ✅ 120mm HDB fan, quiet operation
- ✅ Compact 140mm depth, active cooling
- ✅ Full protections: OCP/OVP/OPP/OTP/SCP
| Total power | 850 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 9 A |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 840 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 70 A |
| Max output current (+5V) | 20 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current, Over power, Under voltage, Over total voltage, Over voltage, Short circuit, Over temperature |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| On/off switch | Yes |
| Operating temperature (T-T) | 0 - 50 °C |
| Cables included | AC, CPU (4+4 pin), PCIe (12V-2x6 x1, 6+2-pin x3), SATA, Peripheral (Molex) |
| Certification | 80 PLUS Gold, BSMI, C-tick, CB, CCC, CE, cTUVus, EAC, FCC, TUV, UKCA |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Package type | Box |
| PCIe connectors | 1x 12V-2x6 (600W), 3x 6+2-pin |
| EPS/ATX12V connectors | 2x 4+4-pin |
| Warranty | 7 years |
