CPU Support: Socket Intel LGA1200 for 10th/11th Gen IntelCore™ Processors, Pentium/Gold/Celeron Processors
-
Chipset: Intel Z590
-
MB Size: ATX
-
Memory Support: 4 DIMM DDR4 Sockets for non-ECC un-buffered DDR4 RAM up to 5333MHz (OC). Max 128GB. Supports Dual Channel Architecture, supports Intel Extreme Memory Profile (XMP)
-
VGA: Intel UHD Graphics, only with Intel CPU that incorporate Intel UHD Graphics GPU
-
VGA Out: 1x HDMI v2.0b with HDR port (supports a maximum resolution of 4K @60Hz), 1x DisplayPort v1.4 (supports a maximum resolution of 4K @60H). Supports 2-Way AMD® CrossFire™ Technology
-
Slots: 2x PCI-E (x16) (supports up to PCIe 4.0 for 11th Gen Intel® CPU), 2x PCI-E (x1) v3.0
-
Storage: 6x SATA3 6Gbps ports supports RAID 0/1/5/10. 3x M.2 slots supports raid 0/1 (M2_1 available only on 11th Gen Intel® CPU, supports up to PCIe 4.0x4, 2242/ 2260/ 2280/ 22110 storage devices, M2_2 & M2_3 supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices). Supports Intel® Smart Response Technology for Intel Core™ processors. Intel Optane Memory Ready
-
NIC: 1x Intel® I225-V 2.5Gbps LAN controller
-
WiFi 6: Intel® Wi-Fi 6E AX210. The Wireless module is pre-installed in the M.2 (Key-E) slot
-
Audio: 7.1 Channel HD Audio
-
I/O: 1x PS/2 Keyboard/mouse combo port, 1x HDMI, 1x DisplayPort, 4(+4int)x USB2.0, 2(+4int)x USB 3.2 Gen1 Type-A, 1x USB3.2 Gen2x2 Type-C, 1x USB3.2 Gen2 Type-A, 1x RJ45 (LAN), 2x Antenna ports, 6 Audio jacks, 1x front panel audio connector, 1x int serial port
-
Special: Extended Heatsink Design, 8+4 Pin power supply, M.2 Shield Frozr, 2.5G Network Solution, Core boost, DDR4 Boost, EZ Debug LED, Frozr AI Cooling
-
Εγγύηση: 3 χρόνια
