Zyxel FWA505 Indoor 5G NR Router - WiFi 6 AX1800, 2x GbE LAN
Zyxel FWA505 is a cloud-managed indoor 5G NR router with WiFi 6 AX1800 dual-band (2.4+5GHz), 2x Gigabit Ethernet ports (LAN/WAN failover), internal antennas. Supports 5G SA/NSA up to 4.7Gbps DL, ideal for home/SOHO with WPA3 security.
Доступно через 2–3 рабочих дней : 5 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Zyxel FWA505 is a compact, cloud-managed 5G NR indoor router designed for reliable high-speed connectivity in homes, small offices, or temporary setups like construction sites. It combines 5G Sub-6 GHz support (NSA/SA modes) with WiFi 6 AX1800 technology, delivering up to 1.77 Gbps wireless speeds across dual-band 2.4 GHz and 5 GHz frequencies for up to 64 devices simultaneously.
Featuring two Gigabit Ethernet RJ-45 ports (LAN2 configurable as WAN for failover), internal high-gain antennas (up to 5 dBi), and advanced security including WPA3, firewall, DoS protection, and Nebula cloud management for easy setup and monitoring. Power consumption peaks at 24W, with dimensions of 103 x 103 x 222 mm and weight of 1.15 kg (packaged: 2.45 kg).
- 5G NR: DL 4.7 Gbps (SA)/3.7 Gbps (NSA), UL up to 2.5 Gbps, FDD/TDD bands
- WiFi 6: 802.11ax, 2×2 MIMO dual-band concurrent
- Ethernet: 2x 1Gbps (LAN/WAN failover)
- Security: WPA3, NAT firewall, MAC/IP filtering
- Management: Nebula cloud app, standalone mode
| Device Type | Indoor 5G NR Router |
| 5G Standard | 3GPP Release 15, NSA/SA, Sub-6 GHz |
| 5G Data Rates | DL 4.7 Gbps (SA) / 3.7 Gbps (NSA); UL 2.5 Gbps (SA) / 1.5 Gbps (NSA) |
| 5G FDD Bands | n1/n3/n5/n7/n8/n20/n28/n77/n78 |
| 5G TDD Bands | n38/n40/n41 |
| LTE Bands | FDD: B1/B3/B5/B7/B8/B20/B28/B32; TDD: B38/B40/B41/B42/B43 |
| WiFi Standard | IEEE 802.11b/g/n/a/ac/ax (WiFi 6) |
| WiFi Speeds | AX1800: up to 1774 Mbps (DBDC) |
| WiFi Bands | Dual-band concurrent 2.4 GHz + 5 GHz (2x2 + 2x2) |
| Ethernet Ports | 2 x 100/1000 Mbps RJ-45 (LAN2 configurable as WAN) |
| Antenna Type | Internal antennas |
| Antenna Gain | <4 dBi (2.4 GHz), <5 dBi (5 GHz); max 5 dBi |
| Security | WPA2/WPA3, NAT/NAPT firewall, DoS detection, MAC/IP filtering, SPI |
| Management | Nebula cloud-managed or standalone |
| Power Consumption | 24 W (peak) |
| Dimensions (W x D x H) | 103 x 103 x 222 mm |
| Weight | 1.15 kg (device); 2.45 kg (packaged) |
| SIM Slots | 1 |
