Thermaltake TOUGHPOWER PF3 750W Fully-Modular 80+ Platinum ATX 3.0 PSU PS-TPD-0750FNFAPU-3
750W fully modular ATX 3.0 PSU with 80 PLUS Platinum efficiency. Includes 1x 12VHPWR (600W), 4x PCIe 6+2 pin, 8x SATA. 120mm FDB fan, Smart Zero Fan, Japanese caps,
Доступно через 6–10 рабочих дней : 500 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Thermaltake Toughpower PF3 750W is a premium fully modular ATX 3.0 power supply certified 80 PLUS Platinum for exceptional energy efficiency. Designed for modern high-performance PCs, it features a native PCIe 5.0 12+4 pin (12VHPWR) connector rated for 600W, perfect for next-gen GPUs like NVIDIA RTX 40 series, plus 4x PCIe 6+2 pin connectors for versatile GPU and PCIe support. It delivers a powerful single +12V rail with 62.5A (750W) capacity, ensuring stable power under heavy loads.
Built with 100% high-quality Japanese electrolytic capacitors, it offers ultra-low ripple noise (<30mV) and strict voltage regulation (<±2%). The ultra-quiet 120mm fluid dynamic bearing (FDB) fan with Smart Zero Fan mode auto-adjusts speed based on load for silent operation. Compact dimensions (150x150x86mm) fit most cases, with active PFC, full protections, and universal 100-240V input. Ideal for gaming rigs and workstations.
- ✅ 80 PLUS Platinum certified efficiency
- ✅ Fully modular flat black cables
- ✅ ATX 3.0 & PCIe 5.0 compliant
- ✅ 1x 12VHPWR + 4x 6+2 PCIe connectors
- ✅ 8x SATA, 4x Molex, 24-pin ATX, EPS
- ✅ Smart Zero Fan & Japanese capacitors
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 10 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 750 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62.5 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Hold time | 17 ms |
| Motherboard power connector | 24-pin ATX |
| Motherboard power cable length | 60 cm |
| Number of SATA power connectors | 8 |
| SATA power cable length | 150.500 mm |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| Peripheral (Molex) power cable length | 150.500 mm |
| PCI Express power connectors (6+2 pin) | 4 |
| PCI Express power connectors (12+4 pin) | 1 |
| PCI Express power connectors (12+4 pin) cable length | 600 mm |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.0 |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Operating temperature (T-T) | 0 - 40 °C |
| Smart Zero Fan | Yes |
| Japanese capacitors | 100% |
| Ripple noise | <30mV |
