Gigabyte GA-X870 AORUS Elite WiFi7 AM5 ATX MB DDR5 256GB PCIe5 WiFi7
Gigabyte GA-X870 AORUS Elite WiFi7: AM5 ATX MB, AMD X870, DDR5 256GB (4xDIMM), 16+2+2 VRM, 3x PCIe5 M.2 + PCIe5 GPU, WiFi7/BT5.4, 2.5GbE, USB4, black.
Доступно через 4–6 рабочих дней : 15 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Gigabyte GA-X870 AORUS Elite WiFi7 is a premium AM5 ATX motherboard based on the AMD X870 chipset, designed for Ryzen 7000/8000/9000 series processors. It features a robust 16+2+2 phase VRM with 60A stages for stable overclocking, supporting up to 256GB DDR5 RAM at 8000MHz+ (OC) across 4 DIMM slots with EXPO profiles.
Storage and expansion are top-tier with 4x M.2 slots (3x PCIe 5.0 x4, 1x PCIe 4.0), 4x SATA III, and PCIe slots including 1x PCIe 5.0 x16 for GPUs, plus PCIe 4.0/3.0 slots. Connectivity shines with Wi-Fi 7 (MediaTek MT7925), Bluetooth 5.4, 2.5GbE LAN (Realtek), dual USB4 (40Gbps), multiple USB 3.2 ports, HDMI 2.1, and 2x DisplayPort 1.4. Audio is handled by Realtek ALC1220 7.1-channel.
- Key Features: PCIe 5.0 GPU/M.2 support, USB4, Wi-Fi 7, EZ-Latch for easy builds, Q-Code debug LED, Sensor Panel Link.
- Ideal for: Gaming, content creation, high-end workstations.
- VRM Cooling: Effective heatsinks keep temps low under load.
- BIOS: User-friendly UEFI with multi-theme UI and Q-Flash.
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Motherboard chipset | AMD X870 |
| Motherboard form factor | ATX |
| Maximum internal memory | 256 GB |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| VRM Phases | 16+2+2 (60A stages) |
| Number of M.2 slots | 4 (3x PCIe 5.0, 1x PCIe 4.0) |
| Number of SATA III connectors | 4 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| LAN controller | Realtek RTL8125 |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| WLAN controller model | MediaTek MT7925 |
| Bluetooth version | 5.4 |
| USB4 Gen 2x2 ports quantity | 2 |
| Audio chip | Realtek ALC1220 |
| Product colour | Black |
| Width | 305 mm |
| Depth | 244 mm |
| Height | 35 mm |
| Weight | 2.4 kg |
| Package width | 335 mm |
| Package depth | 270 mm |
| Package height | 80 mm |
| Package weight | 2.74 kg |
| Warranty period | 3 year(s) |
