Fortron Twins PRO 500 Redundant 500W Hot-Swappable PSU 80 PLUS Gold PS/2
Redundant 500W hot-swappable PSU with dual PS2 modules, 80 PLUS Gold efficiency, non-modular cables. Ideal for ATX/PS2 servers, home NAS; ensures zero downtime on failure.
Доступно через 8–10 рабочих дней : 1 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Fortron Twins PRO 500 is a redundant dual-module power supply designed for standard ATX or PS2 chassis, perfect for mail, web, or home servers. Its hot-swappable design ensures stable power; if one module fails, the other instantly takes over, preventing any downtime.
Featuring a modular system that distributes load for efficiency and quiet operation, it includes black ribbon cables for better heat dissipation, cable management, and aesthetics. A power cord locking device prevents accidental disconnects. Syncs with FSP Guardian software via USB for real-time monitoring of power, efficiency, and temperatures.
- 80 PLUS Gold certified, ≥90% efficiency
- Single +12V rail (41.76A), Active PFC
- Connectors: 20+4pin ATX, 4+4pin EPS, 4x PCIe (6+2pin), 6x SATA, 2x Molex
- 2x 40mm DBB fans, full protections (OCP/OVP/OPP/OTP/SCP/UVP)
- Dimensions: 190x150x86mm, made in China
| Total power | 500 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 8-4 A |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 W |
| Combined power (+5V) | 130 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 41.76 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| Efficiency | 90% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| PCI Express power connectors (6+2 pin) | 4 |
| CPU power connector (4+4 pin) | Yes |
| Cabling type | Non-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | Server |
| Power supply unit (PSU) form factor | PS/2 |
| Bearing technology | DBB |
| Product colour | Black |
| Fan diameter | 4 cm |
| Number of fans | 2 fan(s) |
| Cables included | CPU, PCIe, SATA |
| Width | 86 mm |
| Depth | 150 mm |
| Height | 190 mm |
| Harmonized System (HS) code | 84733020 |
| Model / P/N | FSP500-50RAB |
