Dahua PoE Gigabit Switch 16ports 240W Cloud Managed - CS4220-16GT-240 - 16ports 240W Cloud Managed

Артикул:
Бренд: Dahua
Штрихкод:
340.00 €

Cloud-managed PoE switch with 16 Gigabit ports and 240W total PoE budget, supports 802.3af/at and 802.3bt standards.

Доступно через 2–3 рабочих дней : 5 шт.

For any questions about this item, availability, or delivery times, please contact us at 22 270068

  • Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x, IEEE802.3ab,IEEE802.3z standards.
  • Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards.
  • Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE.
  • A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof.

Basic

  • Switching Capacity : 40 Gbps
  • Packet Forwarding Rate : 29.76 Mpps
  • Description of Function Slots : Port 1-16: 16 × RJ-45 10/100/1000 Mbps (PoE); Port 17-18: 2 × RJ-45 10/100/1000 Mbps (uplink); Port 19-20: 2 ×SFP 1000 Mbps (uplink)
  • PoE Power : Port 1-2 ≤ 90 W, Port 3-16 ≤ 30 W, total ≤ 240 W
  • Layer : Layer 2
  • Operating Temperature : –10 °C to +55 °C (+14 °F to +131 °F)
  • Operating Humidity : 5% –95% (RH), non-condensing
  • Power Supply : Built-in power supply: 100–240 VAC, 47–63 Hz, max 4 A
  • Power Consumption : Idling: ≤8.3 W ; Full load: 265 W
  • Statics Protection : Air discharge: 8 kV; Contact discharge: 6 kV
  • Lightning Protection : Common mode: 4 kV; Differential mode: 2 kV
  • Net Weight 😛 2.37 kg (5.21 lb)
  • Product Dimensions : 440 mm × 220 mm × 44 mm (17.32″ × 8.66″ × 1.73″) (L × W × H)

Hardware

  • PoE : Yes
  • Ethernet Port : 16
  • Reset Button : 1
  • Storage Temperature : –40 °C to +70 °C (–40 °F to +158 °F)
  • Storage Humidity : 5%–95% (RH), non-condensing

Performance

  • MTBF : 86.94 years
  • Packet Buffer Size : 4 Mbit
  • Jumbo Frame : 15K Byte
  • MAC Table Size : 8K
  • VLAN Number : 32
  • Communication Standard : IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab; IEEE802.3z

Feature

  • PoE Protocol : IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
  • PoE Power Consumption Management : Yes
  • PoE Pin Assignment : 1,2,4,5（V+）,3,6,7,8（V-）
  • Long Distance PoE Transmission : Yes
  • Ethernet Loop Protection : STP/RSTP
  • VLAN Function : Port-based VLAN
  • IEEE 802.3x Flow Control : Yes
  • DHCP Function : DHCP Client
  • Equipment Management : Web management; App management

General

  • Gross Weight : 3.02 kg (6.64 lb)
  • Packaging Dimensions : 540 mm × 342 mm × 90 mm (21.26″ × 13.46″ × 3.54″) (L × W × H)
  • Casing Material : Sheet metal
  • Installation : Desktop mount; rack mount
  • Certifications : CE

Packing List

  • Quick Start Guide × 1; Legal and Regulatory Information × 1; Power cord × 1; Rack-mount kit × 1
