Chieftec Vita BPX-850-S 850W 80 Plus Bronze PSU - Black
850W 80 Plus Bronze certified PSU with non-modular cabling, 120mm silent fan, and comprehensive protection. Ideal for mainstream gaming and desktop systems with stable power delivery.
Доступно через 4–6 рабочих дней : 2 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Chieftec Vita Series BPX-850-S is an 850W power supply designed for mainstream gaming and desktop systems. Built on DC-to-DC technology with Active Power Factor Correction (PFC), it delivers stable and efficient power to all system components. The unit is 80 PLUS Bronze certified, ensuring reliable energy efficiency under typical load conditions.
This ATX form factor PSU features a non-modular cabling design with extra-long native black cables, making it suitable for larger PC cases. The 120mm silent fan with automatic speed control optimizes the balance between cooling performance and noise levels. The power supply includes comprehensive protection features to safeguard your system.
Key specifications and features:
- Continuous power output: 850W
- 80 PLUS Bronze efficiency certification
- Active PFC (Power Factor Correction)
- 120mm silent fan with automatic speed control
- Non-modular fixed cabling design
- Connectors: 1x 20+4 pin ATX, 2x 4+4 pin EPS, 2x 6+2 pin PCIe, 6x SATA, 2x Molex
- Protection: OCP, OVP, UVP, SCP, OPP, OTP, SIP
- Dimensions: 150 x 140 x 86 mm
- Weight: 1.9 kg (unit), 2.7 kg (boxed)
| Model | BPX-850-S |
| Total Power Output | 850 W |
| AC Input Voltage | 100 - 240 V |
| AC Input Frequency | 50 - 60 Hz |
| Power Factor Correction (PFC) | Active (0.9) |
| Form Factor | ATX |
| ATX12V Standard | ATX 12V 2.53 |
| Efficiency Certification | 80 PLUS Bronze |
| Cabling Type | Non-modular |
| Cooling System | Active |
| Fan Size | 120 mm |
| Fan Bearing Type | Hydrodynamic |
| Fan Speed Control | Automatic (AFC) |
| Motherboard Power Connector | 1x 20+4 pin ATX |
| Motherboard Power Cable Length | 65 cm |
| EPS CPU Power Connectors | 2x 4+4 pin EPS 12V |
| CPU Power Cable Length | 70 cm |
| PCIe GPU Power Connectors | 2x 6+2 pin PCIe |
| PCIe Power Cable Length | 50 cm |
| SATA Power Connectors | 6x SATA |
| SATA Power Cable Length | 450 mm |
| Molex (4-pin) Connectors | 2x Molex |
| Molex Power Cable Length | 450 mm |
| +12V1 Output | 70.8 A |
| +5V Output | 18 A |
| +3.3V Output | 18 A |
| +5VSB Output | 3.0 A / 15 W |
| -12V Output | 0.3 A / 3.6 W |
| Protection Features | OCP, OVP, UVP, SCP, OPP, OTP, SIP |
| Dimensions (D x W x H) | 150 x 140 x 86 mm |
| Weight (Unit) | 1.9 kg |
| Weight (Boxed) | 2.7 kg |
| Color | Black |
| EAN Code | 0753263078636 |
| Warranty | 2 years |
| Purpose | PC/Server |
