Broadcom MegaRAID 9540-8i 12Gb/s PCIe 4.0 x8 RAID 0/1/10 8 Internal Ports
Broadcom MegaRAID 9540-8i RAID controller. PCIe 4.0 x8, 8 internal SAS/SATA 12Gb/s & NVMe ports. RAID 0,1,10,JBOD. SAS3808 ROC. Low profile MD2 form factor. MTBF 3M hours. Max 63 SAS/SATA +4 NVMe devices. Power 6W.
Доступно через 6–10 рабочих дней : 15 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Broadcom MegaRAID 9540-8i is a high-performance Tri-Mode storage adapter designed for data centers, cloud, and HPC environments. It delivers 12Gb/s SAS/SATA and PCIe Gen4 NVMe connectivity via PCIe 4.0 x8 host interface, providing twice the bandwidth of previous generations with 75% more IOPS.
Featuring the SAS3808 RAID-on-Chip controller and 1x SFF-8654 (SlimSAS) connector for 8 internal ports, it supports up to 63 SAS/SATA drives and 4 NVMe devices. RAID levels include 0, 1, 10, JBOD with features like fast rebuild and hot spare support. Low profile MD2 form factor (155.7×68.9mm) fits most servers. Operating temp 0-55°C, MTBF over 3,000,000 hours, typical power 6W.
- ✅ PCIe 4.0 x8 host interface
- ✅ 8 internal ports: SAS 12Gb/s, SATA 6Gb/s, PCIe 4.0 NVMe
- ✅ RAID 0, 1, 10, JBOD
- ✅ Low profile card, no cache
- ✅ Broad OS support: Windows, Linux, VMware, FreeBSD
| Host Interface | PCIe 4.0 x8 |
| Internal Ports | 8 |
| Internal Connectivity | 1 x SFF-8654 (SlimSAS) |
| RAID Levels | 0, 1, 10, JBOD |
| Data Transfer Rate | 12 Gbit/s SAS / 6 Gbit/s SATA / PCIe 4.0 NVMe |
| Controller Chip | SAS3808 |
| Max SAS/SATA Devices | 63 |
| Max NVMe Devices | 4 |
| Form Factor | Low Profile MD2 (155.7 x 68.9 mm) |
| MTBF | 3000000 h |
| Operating Temperature | 0 - 55 °C |
| Power Consumption | 6 W |
| OS Support | Windows, VMware, RHEL, SUSE, Ubuntu, Citrix, CentOS, Debian, Oracle, Fedora, FreeBSD |
| MPN | 05-50134-03 |
| Features | S.M.A.R.T. support, Universal Backplane Management ready |
