Barebone Mini-PC XPC nano NT10H5
Shuttle Nano PC NT10H5, Intel Core Ultra 5 125H, Intel Arc graphics, 2xHDMI, 2xUSB 4.0 (DP), 2×2.5Gbit LAN, VESA, 24/7 Dauerbetrieb, 1L Größe PC, Mini-PC Barebone, Intel SoC, DDR5-SDRAM, PCI Express, 120 W
Доступно через 6–10 рабочих дней : 9 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
Shuttle Nano PC NT10H5, Intel Core Ultra 5 125H, Intel Arc graphics, 2xHDMI, 2xUSB 4.0 (DP), 2×2.5Gbit LAN, VESA, 24/7 Dauerbetrieb. Gehäusetyp: 1L Größe PC, Produkttyp: Mini-PC Barebone. Motherboard Chipsatz: Intel SoC, BIOS-Typ: UEFI AMI. Unterstützte Arbeitsspeicher: DDR5-SDRAM, Anzahl der Speichersteckplätze: 2, RAM-Speicher maximal: 64 GB. Unterstützte Speicherlaufwerke: SSD, Speicherlaufwerk Schnittstelle: PCI Express. Anzahl Ethernet-LAN-Anschlüsse (RJ-45): 2. Kühlung: Aktiv. Stromversorgung: 120 W
| Prozessorhersteller | Intel |
| Prozessorfamilie | Intel Core Ultra 5 |
| Prozessorgeneration | Intel Core Ultra (Serie 1) |
| Prozessor | 125H |
| Anzahl Prozessorkerne | 14 |
| Prozessor-Threads | 18 |
| Prozessor Boost-Frequenz | 4,5 GHz |
| Leistungskerne | 4 |
| Effiziente Kerne | 8 |
| Leistungskern maximale Turbofrequenz | 4,5 GHz |
| Effizienter Kern maximale Turbofrequenz | 3,6 GHz |
| Low Power Efficient-Core maximale Turbofrequenz | 2,5 GHz |
| Leistung Basisfrequenz des Kerns | 1,2 GHz |
| Effiziente Basisfrequenz des Kerns | 0,7 GHz |
| Low Power Efficient-Core Basisfrequenz | 700 MHz |
| Eingebauter Prozessor | Ja |
| Prozessor-Cache | 18 MB |
| Installierter interner Speicher | Nein |
| Arbeitsspeicher Typ | SO-DIMM |
| Anzahl der Speichersteckplätze | 2 |
| RAM-Speicher maximal | 64 GB |
| Unterstützte Arbeitsspeichergeschwindigkeit | 5600 MHz |
| Unterstützte Arbeitsspeicher | DDR5-SDRAM |
| Speicherkanäle | Zweikanalig |
| Speicherspannung | 1.1 V |
| ECC | Nein |
| Ohne ECC | Ja |
| Installierte Speichertreiber | Nein |
| Unterstützte Speicherlaufwerke | SSD |
| unterstützte Speicherlaufwerksgrößen | M.2 |
| SSD-Formfaktor | M.2 |
| Speicherlaufwerk Schnittstelle | PCI Express |
| NVMe | Ja |
| Integrierter Kartenleser | Ja |
| Kompatible Speicherkarten | SD |
| Eingebaute Grafikadapter | Ja |
| Grafikkarte-Familie | Intel |
| Eingebautes Grafikkartenmodell | Intel Arc Graphics |
| Maximale Auflösung | 3840 x 2160 Pixel |
| Anzahl der Display unterstützt | 4 |
| Motherboard Chipsatz | Intel SoC |
| BIOS-Typ | UEFI AMI |
| Trusted Platform Module (TPM) | Ja |
| Trusted Platform Module (TPM) Version | 2.0 |
| Audio-Chip | Realtek ALC269 |
| Eingebaute Lautsprecher | Nein |
| Ethernet/LAN | Ja |
| WLAN | Nein |
| LAN-Controller | Intel I226-V |
| Anzahl USB 2.0 Anschlüsse | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Anschlüsse vom Typ A | 5 |
| Anzahl USB4 Gen 2×2-Ports | 2 |
| Anzahl HDMI-Anschlüsse | 2 |
| HDMI-Version | 2.0 |
| Kombinierter Kopfhörer-/Mikrofon-Anschluss | Ja |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 2 |
| Gleichstrom-Anschluss (DC) | Ja |
| Gehäusetyp | 1L Größe PC |
| Produktfarbe | Schwarz |
| Kühlung | Aktiv |
| Ein-/Ausschalter | Ja |
| Gehäusematerial | Kunststoff |
| Kabelsperre-Slot | Ja |
| Slot-Typ Kabelsperre | Kensington |
| VESA-Halterung | Ja |
| Panel-Montage-Schnittstelle | 75 x 75,100 x 100 mm |
| Produkttyp | Mini-PC Barebone |
| Konformitätsbescheinigungen | BSMI, CE, Eidgenössische Kommunikationskommission (FCC), RoHS, cTUVus |
| Warentarifnummer (HS) | 84733080 |
| Unterstützt Windows-Betriebssysteme | Windows 11 x64 |
| Unterstützte Linux-Betriebssysteme | Ja |
| Nachhaltigkeitszertifikate | ENERGY STAR, ErP |
| Netzteiltyp | Externer AC-Adapter |
| Stromversorgung | 120 W |
| Anzahl von Stromversorgungseinheiten | 1 |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Netzteil Ausgangsspannung | 19 V |
| AC-Adapter Ausgangssstrom | 6,32 A |
| Betriebstemperatur | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Breite | 132 mm |
| Tiefe | 143 mm |
| Höhe | 55 mm |
| Gewicht | 800 g |
| Paketgewicht | 1,7 kg |
| Netzkabel enthalten | Ja |
| AC-Netzadapter | Ja |
| Schnellstartübersicht | Ja |
