Backplane - BP-4724-12G
460.50 €
Optional 24-slot backplane with expander chipset for 19″ storage enclosures 4U 4724/4736; transfer speed up to 12G; 1x SFF-8643 output, 2x SFF-8643 input.
Доступно через 6–10 рабочих дней : 30 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Inter-Tech BP-4724-12G is an optional 24-fold backplane with expander chipset for the 19″ storage enclosures 4U 4724 and 4U 4736 with a transmission speed of up to 12G. The backplane replaces the already pre-installed 6G backplane. The backplane is connected to the controller (not included in delivery) via an SFF-8643 connection and also offers two additional SFF-8643 inputs. The power supply runs via five power connections.
| Typ | Backplane |
| EAN | 4260455647359 |
| Manufacturer no. | 88887358 |
| suitable for | 19" storage enclosures 4U 4724 and 4U 4736 |
| Hot swap support | No |
| More information | Transfer speed max. 12G, 1x SFF-8643 output, 2x SFF-8643 input |
| Dimensions | Width: 423mm x Height: 164mm x Depth/Length: 25mm |
