ASUS TUF B650-PLUS GAMING WIFI AM5 ATX MB DDR5 128GB WiFi6 2.5GbE
AM5 ATX motherboard for Ryzen 7000/8000 series. DDR5 up to 128GB OC 6400+, 3x M.2 (1x PCIe5), 4x SATA, WiFi6, BT5.2, 2.5Gb LAN, USB4, mil-grade TUF durability.
Доступно сразу после подтверждения : 1 шт.
For any questions about this item, availability, or delivery times, please contact us at 22 270068
ASUS TUF GAMING B650-PLUS WIFI delivers rock-solid performance for AMD Ryzen 7000/8000 series processors on AM5 socket. Built with military-grade TUF components, 12+2 power stages rated 60A, ProCool connectors, and enlarged VRM/M.2 heatsinks for marathon gaming stability.
Comprehensive features include DDR5 dual-channel up to 128GB (OC 6400+MHz with EXPO), PCIe 5.0 M.2 slot, WiFi 6 (802.11ax), Bluetooth 5.2, 2.5Gb Ethernet, USB 3.2 Gen2x2 Type-C, and Thunderbolt header. UEFI BIOS with EZ/Advanced modes, Armoury Crate for RGB/fan control, and Q-LED diagnostics simplify building.
Immersive gaming with Realtek 7.1 audio, DTS processing, AI Noise Cancelation, and Aura Sync RGB headers. TUF Protection (SafeSlot, LANGuard, stainless I/O) ensures longevity.
- ✅ PCIe 5.0 M.2 + 2x PCIe4 M.2 + 4x SATA III
- ✅ WiFi 6 + 2.5Gb LAN + BT 5.2
- ✅ 12+2 DrMOS power stages (60A)
- ✅ DDR5 128GB max, EXPO overclocking
- ✅ USB4/Thunderbolt header + multiple USB-C
- ✅ Comprehensive cooling + Fan Xpert 4
| Manufacturer Part Number | 90MB1BZ0-M0AAY0 |
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Compatible processor series | AMD Ryzen 7000 Series, Ryzen 8000 Series |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory channels | Dual-channel |
| Maximum internal memory | 128 GB |
| Supported memory clock speeds | 4800-7600+ MHz (OC) |
| Number of M.2 (M) slots | 3 (1x PCIe 5.0, 2x PCIe 4.0) |
| Number of SATA III connectors | 4 |
| Power stages | 12+2 (60A DrMOS) |
| Wi-Fi | Yes (Wi-Fi 6 802.11ax) |
| Bluetooth | Yes (5.2) |
| Ethernet LAN | 2.5 Gigabit Ethernet |
| Audio output channels | 7.1 channels |
| Motherboard form factor | ATX |
| PCI Express x16 (Gen 4.x) slots | 2 |
| PCI Express x1 (Gen 4.x) slots | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Thunderbolt headers | 1 |
| Package width | 338 mm |
| Package depth | 273 mm |
| Package height | 68 mm |
| Package weight | 1.36 kg |
