Titan TFD-5010M12Z 50x50x10mm 3-Pin Case Fan 4500RPM
Titan 33349Z (TFD-5010M12Z) 50x50x10mm case fan with 3-pin motherboard + Molex connectors. 4500 RPM speed delivers 14.67 m³/h (8.65 CFM) airflow at
Available in 2–5 business days : 8 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Titan 33349Z, model TFD-5010M12Z, is a compact 50x50x10mm DC cooling fan designed for efficient airflow in small form factor PCs, servers, and embedded systems. It operates at 12V with both 3-pin motherboard connector for speed control and Molex power connector for versatility. Featuring a z-axis bearing, it ensures smooth, reliable operation with low friction and extended lifespan.
With a high speed of 4500 RPM, this fan provides maximum airflow of 14.67 m³/h (8.65 CFM) while maintaining noise levels under 23 dBA, making it suitable for noise-sensitive environments. The low-profile 10mm thickness allows installation in tight spaces where larger fans cannot fit.
- Dimensions: 50 x 50 x 10 mm
- Speed: 4500 RPM
- Airflow: 14.67 m³/h
- Noise: <23 dBA
- Connectors: 3-pin + Molex
- Bearing: Z-axis
| Model | TFD-5010M12Z / 33349Z |
| Fan Dimensions | 50 x 50 x 10 mm |
| Rated Voltage | 12 VDC |
| Speed | 4500 RPM |
| Max Airflow | 14.67 m³/h (8.65 CFM) |
| Noise Level | <23 dBA |
| Bearing Type | Z-Axis Bearing |
| Connectors | 3-pin (motherboard) + Molex |
| Power Connector | 12V Molex |
