Inline 76617L SATA 6Gb/s Controller 4x PCIe 2.0 x1
Inline 76617L PCIe 2.0 x1 SATA controller adds 4x 6Gb/s ports. Supports AHCI, NCQ, hot-swap. Backward compatible with SATA 3/1.5Gb/s. LED activity indicator. For Win/Linux/Mac. ASMedia ASM1064.
Available in 2–5 business days : 3 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Inline 76617L is a high-performance PCI Express SATA controller card that expands your system with four SATA 6Gb/s ports using a native PCIe 2.0 x1 interface. Based on the reliable ASMedia ASM1064 chipset, it delivers speeds up to 6 Gb/s and is fully compliant with Serial ATA Revision 3.2, while remaining backward compatible with 3.0 Gb/s and 1.5 Gb/s SATA devices.
Key features include AHCI mode, Native Command Queuing (NCQ), FIS-based port multiplier support, and hot-plug/hot-swap functionality. The unique HDD activity LED blinks during read/write operations on connected drives. It fits in any PCIe x1 slot (and larger x2/x4/x8/x16) and includes a low-profile bracket for compact builds. Compatible with Windows 10/8/7 (32/64-bit), Linux, and Mac OS.
- 4x Internal SATA 6Gb/s ports
- PCIe 2.0 x1 host interface (5 Gbps bandwidth)
- Supports bootable drives and hot-swap
- HDD activity LED indicator
- Package: Card, low-profile bracket, manual
| Chipset | ASMedia ASM1064 |
| Host Interface | PCIe 2.0 x1 (backward compatible x2/x4/x8/x16) |
| SATA Ports | 4 x SATA 6Gb/s (internal) |
| Max Transfer Rate | 6 Gb/s per port |
| SATA Specification | Serial ATA Revision 3.2 |
| Backward Compatibility | SATA 3.0 Gb/s, 1.5 Gb/s |
| Modes Supported | AHCI, Native Command Queuing (NCQ) |
| Hot-Swap | Yes |
| Port Multiplier | FIS switch / command switch |
| Activity LED | Yes (HDD read/write indicator) |
| OS Support | Windows 10/8/7 (32/64-bit), Linux, Mac OS |
| Package Contents | PCIe card, low-profile bracket, user manual |
| Form Factor | Low-profile / full-height bracket |
