Inline 66907 Mini-PCIe 2.0 SATA 2x 6Gbps RAID 0/1/SPAN
Inline 66907 Mini-PCIe card with ASMedia ASM1061R chipset adds 2x SATA 6Gbps ports supporting RAID 0/1/SPAN. PCIe 2.0 x1 interface, full-size Mini-PCIe form factor, internal vertical SATA connectors. Windows compatible with built-in drivers.
Available in 2–5 business days : 4 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Inline 66907 is a full-size Mini-PCIe expansion card that provides two internal SATA 6Gbps ports for connecting HDDs and SSDs. Based on the ASMedia ASM1061R chipset, it supports PCIe 2.0 x1 with up to 2.5Gb/s bandwidth and complies with SATA Rev. 3.2 and AHCI 1.3 specifications.
It enables RAID 0, RAID 1, and SPAN modes with automatic rebuild, Native Command Queue (NCQ), and compatibility with SATA III/II/I drives. Ideal for systems needing additional high-speed storage without external controllers. Supported by built-in Windows drivers (8.1/8/7/Vista).
- 2x vertical internal SATA 6Gb/s ports
- RAID 0/1/SPAN with hardware engine
- PCIe Gen2 x1 to SATA bridge
- Supports NCQ and port multiplier
- Includes manual; requires free Mini-PCIe slot
| Chipset | ASMedia ASM1061R |
| Host Interface | PCIe 2.0 x1 (Mini-PCIe) |
| SATA Ports | 2x SATA 6Gb/s (internal, vertical) |
| RAID Support | RAID 0, RAID 1, SPAN (JBOD) |
| SATA Specification | SATA Rev. 3.2, AHCI 1.3 |
| Supported Speeds | 6Gb/s, 3Gb/s, 1.5Gb/s |
| Form Factor | Full-size Mini-PCIe |
| OS Support | Windows 8.1/8/7/Vista (built-in drivers) |
| Features | NCQ, Port Multiplier, Automatic Rebuild |
| Package Contents | Mini-PCIe card, manual |
