Be quiet Straight power 11 1000W BN285 80 plus
  • Be quiet Straight power 11 1000W BN285 80 plus
  • Be quiet Straight power 11 1000W BN285 80 plus
  • Be quiet Straight power 11 1000W BN285 80 plus
  • Be quiet Straight power 11 1000W BN285 80 plus

Be quiet Straight power 11 1000W BN285 80 plus

PSU0068
€190.00
Tax included
Quantity
Available upon pre order
  • Power: 1000 W
  • PCI-E 6+2 Pin: 6
  • SATA connector: 12
  • 80 PLUS Gold  Certificate
  • Modular cables
  • Warranty 5 Years

Specification

  • Power 1000W Power Supply
  • Comforms ATX12V V2.4 and EPS 2.92 standard
  • AC Input: Voltage 100-240V, Current 10-5A, Frequency 50-60Hz
  • DC Out: +3,3V max 25A, +5V max 25A, +12V1 max 22A, +12V2 max 22A, +12V3 max 30A, +12V4 max 30A, -12V max 0,5A, +5Vsb max 3A
  • 93% Energy Efficiency (80+ Gold 230V EU Certified). Active PFC
  • Connectors:
    • 1x ATX-Motherboard (20+4-pin)
    • 1x P8 (CPU)
    • 1x P4+4 (CPU)
    • 6x PCI-e 6+2-pin (GPU)
    • 4x PATA 4-pin
    • 11x SATA 15-pin (HDD, Drives)
    • 1x FDD (Floppy)
  • Fan Type: be quiet! Silent Wings 3 with 135mm fan
  • OCP (over current protection), OVP (over Voltage protection), UVP (under Voltage protection), SCP (short circuit protection), OTP (over temperature protection), OPP (over power protection)
  • MTBF: 100.000 Hours
  • Safety Approvals: CE, CB, TUV, FCC, cTUVus, RCM, CU, BSMI, CCC
  • Dimesions without cable: 170(L)x150(W)x86(D)mm
  • Package Dimensions: 328(L)x248(W)x102(D)mm
  • Total weight: 1.85Kg
  • Color: Black
  • Warranty: 5 years

Main Features

PSU Form Factor
ATX
PSU 80+ Certificate
Gold
PSU Power
1000W
PSU Connectivity PCI-E 6 plus 2 pin
6
PSU Cable Managment
Full Modular
PSU Connectivity Main 20+4 pin
1
PSU Connectivity CPU 4 plus 4 pin
1
PSU Connectivity S-ATA
10
PSU RGB
No
