Power Supply Be quiet Dark Power pro 13 1300W BN331

PSU0288
490,00 €
με ΦΠΑ
Ποσότητα
Το προϊόν δεν είναι διαθέσιμο για παραγγελία
  • Power: 1300 W
  • 2x 12VHPWR cable/W
  • 6 x (6+2) pin PCIe 5.0
  • 16 x SATA: 5 x PATA;
  • Full Modular cables
  • 80 PLUS Titanium Certificate
  • Warranty 10 Years

Specification

  • Dark Power 13 1300W Full Modular Power Supply.
  • Compliant ATX 3.0, EPS 2.92 standard. Full support for PCI-E 5.0 GPUs and GPUs with 6+2 pin connector.
  • AC Input: Voltage 100-240V, Current 16/8A, Frequency 50-60Hz.
  • DC Out: +3,3V max 25A, +5V max 25A, +12V1 max 35A, +12V2 max 35A, +12V3 max 40A, +12V4 max 40A, +12V5 mx 55A, +12V6 max 55A, -12V max 0,5A, +5Vsb max 3,5A. Total Combine Power output 1300W. Power Good signal 100-150 ms.
  • Efficiency: Titanium Energy 80 Plus certification. 91,6% at 10% load, 93,6% at 20% load, 94,4% at 50% load, 92,8% at 100% load.
  • Cables/Connectors: 1x ATX-Motherboard (20+4-pin), 1x P8 (CPU), 1x P4+4 (CPU), 2x 12VHPWR cable/W, 6x PCI-E v5.0 6+2 pin (GPU), 5x PATA, 16x SATA.
  • Fan: Improved and patented frameless Silent Wings fan 135mm. Max fan speed 2400 rpm temperature dependent.
  • Protection: OCP (over current protection), OVP (over voltage protection), UVP (under Voltage protection), SCP (short circuit protection), OTP (over temperature protection), OPP (over power protection), SIP (surge & inrush protection).
  • MTBF: 100.000 Hours.
  • Safety Approvals: CE, CB, TUV, FCC, cTUVus, RCM (Australia), BSMI, CU (Russia), CCC, UKCA.
  • Environmental directives: Energy Star 8.0, Erp, WEEE, RoHs, Triman.
  • Dimensions without cable: 200(L)x150(W)x86(D)mm.
  • Total Weight: 2.41Kg.
  • Color: Black.
  • Warranty: 10 years

Χαρακτηριστικά

Τύπος
ATX
Συνδεσιμότητα PCI-E 6+2 pin
6
Cable Managment
Full Modular
Συνδεσιμότητα 20+4 pin
1
Συνδεσιμότητα CPU (4+4) pin
2
Συνδεσιμότητα S-ATA
16
Συνδεσιμότητα Molex
5
Συνδεσιμότητα PCI-E 12+4 pin (12VHPWR)
Yes

Ειδικοί αριθμοί αναφοράς
