Fixed Lens
Image Sensor : 1/2.8" CMOS
Max. Resolution : 2304 (H) × 1296 (V)
Illumination Distance : Up to 30 m (98.43 ft) (IR) / Up to 20 m (65.62 ft) (Warm light)
Illuminator Number : 2 (IR LED); 2 (Warm light)
Angle Adjustment : -10° to 15°
Lens Type : Fixed-focal
Focal Length : 2.8 mm
Max. Aperture : F1.6
Field of View : H: 95°; V: 53°; D: 110°
PT Lens
Image Sensor : 1/2.8" CMOS
Max. Resolution : 2304 (H) × 1296 (V)
Illumination Distance : Up to 50 m (164.04 ft) (IR) / Up to 40 m (131.23 ft) (Warm light)
Illuminator Number : 2 (IR LED); 2 (Warm light)
Angle Adjustment : Pan: 0° to 352°; / Tilt: 0° to 90°
Lens Type : Fixed-focal
Focal Length : 6 mm
Max. Aperture : F1.6
Field of View : H: 53°; V: 29°; D: 62°
Intelligence
Human Detection : Yes
Vehicle Detection : Yes
Audio and Video
Video Compression : H.265
Video Frame Rate : Main stream: 2304 × 1296@15 fps
sub stream: 640 × 360@15 fps
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Video Bit Rate : H.265: 512 kbps–4096 kbps
Day/Night : Auto(ICR)/Color/B/W
WDR : DWDR
Motion Detection : Yes
Image Rotation : 0°/180°
Built-in MIC : Yes, built-in Mic
Built-in Speaker : Yes, built-in speaker
Audio Compression : G.711a
Network
Network Port : RJ-45 (10/100 Base-T)
Wi-Fi : IEEE 802.11b/g/n/ax 2.412-2.472
GHz,2.4G, ≤20dBm@2400-2483.5MHz
Wi-Fi Pairing : Bluetooth pairing
Storage : Micro SD card (support max. 256 GB)
Management Software : DMSS
Mobile Client : iOS;Android
General
Certifications : CE
Power Supply : 12 VDC
Power Consumption : Basic: 2.3 W / Max.: 10 W (pulling stream+ IR + siren and light active deterrence)
Operating Temperature : –20 °C to +50 °C (–4 °F to +122 °F)
Operating Humidity : ≤95% (RH), non-condensing
Protection : IP66
Casing Material : Plastic
Product Dimensions : 159.4 mm × 119.1 mm × 210 mm (6.28" × 4.69" × 8.27") (L × W × H)
Net Weight : 585 g (1.29 lb)
