ARCTIC P14 PWM PST A-RGB 0dB - 140mm Pressure-Optimized ARGB Fan, PWM
140mm ARCTIC P14 PWM PST A-RGB 0dB fan: 0-1900 RPM PWM, 68.9 CFM airflow, 2 mmH2O pressure, 0.3 Sone noise. Pressure-optimized for radiators/heatsinks with 12 A-RGB LEDs, daisy-chain PST.
Available in 10–14 business days : 40 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The ARCTIC P14 PWM PST A-RGB 0dB is a 140mm pressure-optimized case fan featuring semi-passive 0dB operation. Speed adjusts from 0-1900 RPM via PWM, stopping completely below 5% for silent idle mode while delivering maximum cooling when needed. Equipped with 12 digital A-RGB LEDs compatible with major motherboard brands (ASUS, MSI, Gigabyte, ASRock), it syncs lighting via 5V 3-pin connector or external controller.
Designed for static pressure with 68.9 CFM airflow and 2 mmH2O pressure, it’s ideal for radiators and heatsinks. The Fluid Dynamic Bearing ensures long life and minimal noise (0.3 Sone). PWM PST daisy-chain support simplifies cabling with integrated splitters on both fan and A-RGB cables. Fluid Dynamic Bearing with oil capsule prevents leaks for quiet, durable performance.
- 0dB Mode: Zero RPM below 5% PWM for silent operation
- A-RGB Lighting: 12 LEDs, 5V 3-pin connector
- Pressure Optimized: 2 mmH2O for radiators/heatsinks
- Daisy-Chain: PWM PST + A-RGB splitters
- Bearing: Fluid Dynamic Bearing, 6-year warranty
| Fan Speed | 200–1900 rpm (0 rpm <5% PWM) |
| Airflow | 68.9 cfm | 117.06 m³/h |
| Static Pressure | 2 mmH2O |
| Noise Level | 0.3 Sone |
| Bearing | Fluid Dynamic Bearing |
| Connector | 4-Pin PWM + 4-Pin Socket (PST) |
| A-RGB Connector | 5V 3-Pin |
| Current | Voltage | 0.17 A | 12 V DC |
| Cable Length | 400 mm + 80 mm extension |
| Dimensions | 140 x 140 x 27 mm |
| Weight (Fan) | 225 g |
| Operating Temperature | 0–40 °C |
| Warranty | 6 Years |
| Box Dimensions | 167 x 167 x 34 mm |
| Gross Weight | 297 g |
