SPECIFICATIONS
Display
Panel Size: 65"
Type/ Tech: TFT LCD Module. ADS type, DLED backlight
Display Area (mm): 1428.48 (H) ×803.52 (V) (64.5” diagonal)
Native Resolution: 3840 x 2160
Aspect Ratio: 16:9
Colors: 1.07G (8bits + FRC-)
Brightness: 450 nits (typ.)
Contrast Ratio: 1200:1 (typ.), 5000:1 (DCR enabled)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 hours
Surface Treatment: Anti-Glaire, 3H hardness, Haze 25%
Bezel: 14.7/14.7/14.7/14.7 mm (L/R/T/B)
Orientation: Landscape & Portrait
Platform
Processor: Quad-core ARM Cortex A55
RAM: 4GB
Storage: 32GB
INPUT
HDMI: 2.1x3 ( 3840x2160 @60Hz, HDMI 1 support ARC)
RS-232: x 1
OPS Slot: x 1
WiFi Slot: x 1
OUTPUT
HDMI: 2.0 x1 ( 3840x2160 @60Hz )
SPDIF: x 1
LAN
RJ45: x 1
USB
Type A: 2.0 x 1, 3.0 x 1
Type C: x 1 ( (DP1.2, PD 65W, USB2.0, 100M ethernet)
SPEAKERS
10W x2
Embedded OS
Android 11
POWER
Voltage: 100-240 VAC +/- 10%
Consumption: 88 W(typ.) < 0.5W(off)
OPERATING CONDITIONS
Temperature (º C): 0 to 40℃
Humidity: 10%-90% RH
Operating Hours
7/24
DIMENSIONS (W x H x D)
Physical (inch / mm): 57.61 x 33.0 x 3.21in/ 1463.3 x 838.3 x 81.6mm
Packaging (inch / mm): 63.78 x 37.09 x 8.19 in./1620 x 942 x 208 mm
WEIGHT
Net (lb / kg): 56.0 lbs/25.4 kg
Gross (lb / kg): 73.3 lbs/33.25 kg
REGULATIONS
cTUVus, FCC/ICES003, Energy star 8.0, EPEAT, Mexico NOM , Mexico Energy, EMC/CE , CB, EAC, UkrSEPRO, RCM, LBL, Flicker free, Green BOM, RoHS , ErP, REACH, SCIP, WEEE , Annex I, Annex II, TPCH , Packing waste, CA65
PACKAGE CONTENTS
1. Remote Control with batteries
2. Quick Start Guide
3. Power Cables
4. HDMI cable
5. USB-C cable
6. Wall Mount Screw x 4
7. RS232 adapter
8. Compliance statement
