Technical Specifications
Picture/Display
LCD panel type VA LCD
Backlight type W-LED system
Panel Size 27 inch / 68.5 cm
Display Screen Coating SAG 25%
Effective viewing area 596.736 (H) x 335.664 (V) - at a 1000R curvature*
Pixel format R.G.B. Vertical strip
Aspect ratio 16:9
Maximum resolution HDMI: 2560 x 1440 @ 144 Hz, DP: 2560 x 1440 @ 240 Hz
Pixel Density 108.79 PPI
Response time (typical) 1 ms (Grey to Grey)*
MPRT 0.5 ms
Low Input Lag Yes
Brightness 400 cd/m²
SmartContrast Mega Infinity DCR
Contrast ratio (typical) 3000:1
Pixel pitch 0.2331 x 0.2331 mm
Viewing angle
178º (H) / 178º (V)
@ C/R > 10
Flicker-free Yes
HDR DisplayHDR 400 certified
Colour gamut (typical) NTSC 98.5%*, sRGB 119%*
Picture enhancement SmartImage game
Display colours 16.7 M (8 bit)
Scanning Frequency HDMI: 30 - 230 kHz (H)/48 - 144 Hz (V), DP: 30 - 255 kHz (H)/48 - 240 Hz (V)
SmartUniformity 93 ~ 105%
Delta E < 2 (sRGB)
LowBlue Mode Yes
EasyRead Yes
sRGB Yes
AMD FreeSync™ technology Premium Pro
Connectivity
Signal Input HDMI 2.0 x 2, DisplayPort 1.4 x 2
HDCP HDCP 1.4 (HDMI/DisplayPort), HDCP 2.2 (HDMI/DisplayPort)
USB Hub USB 3.2 Gen 1 / 5 Gbps, USB-B upstream x 1, USB-A downstream x 4 (with 2 for fast charge B.C 1.2)
Audio (In/Out) Audio out
Sync Input Separate Sync
Convenience
MultiView
PIP/PBP mode
2 x devices
User convenience
Power On/Off
Menu/OK
Input/Up
Game Settings/Down
SmartImage game/Back
OSD Languages
Brazil Portuguese
Czech
Dutch
English
Finnish
French
German
Greek
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Spanish
Simplified Chinese
Swedish
Turkish
Traditional Chinese
Ukrainian
Other convenience
Kensington lock
VESA mount (100 x 100 mm)
Plug and Play Compatibility
DDC/CI
Mac OS X
sRGB
Windows 11 / 10 / 8.1 / 8 / 7
Stand
Height adjustment 130 mm
Swivel -/+ 30 degree
Tilt -5/20 degree
Power
On mode 25.9 W (typ.)
Standby mode 0.5 W (typ.)
Off mode 0.3 W (typ.)
Energy Label Class F
Power LED indicator
Operation - White
Standby mode - White (flashing)
Power supply
Internal
100–240 VAC, 50–60 Hz
Dimensions
Product with stand (max height) 606 x 527 x 230 mm
Product without stand (mm) 606 x 370 x 108 mm
Packaging in mm (W x H x D) 785 x 483 x 190 mm
Weight
Product with stand (kg) 6.25 kg
Product without stand (kg) 5.00 kg
Product with packaging (kg) 10.28 kg
Operating conditions
Temperature range (operation) 0°C to 40 °C
Temperature range (storage) -20°C to 60 °C
Relative humidity 20%-80 %
Altitude Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
MTBF 30,000 (Excluded backlight) hour(s)
Sustainability
Environmental and energy RoHS
Recyclable packaging material 100 %
Specific Substances
Mercury free
PVC/BFR free housing
Compliance and standards
Regulatory Approvals
CB
CE Mark
FCC Class B
ICES-003
CU-EAC
EAEU RoHS
TUV/ISO9241-307
TUV-BAUART
Cabinet
Colour Dark Slate
Finish Textured
What's in the box?
Monitor with stand Yes
Cables HDMI cable, DisplayPort cable, USB upstream cable, Power cable
User Documentation Yes
