Technical Specifications
Picture/Display
LCD panel type IPS technology
Adaptive sync Yes
Backlight type W-LED system
Panel Size 23.8 inch/60.5 cm
Display Screen Coating Anti-Glare, 3H, Haze 25%
Effective viewing area 527 (H) x 296.5 (V)
Aspect ratio 16:9
Maximum resolution 1920 x 1080 @ 75 Hz*
Pixel Density 93 PPI
Response time (typical) 4 ms (Grey to Grey)*
Brightness 250 cd/m²
Contrast ratio (typical) 1000:1
SmartContrast 50,000,000:1
Pixel pitch 0.275 x 0.275 mm
Viewing angle
178º (H)/178º (V)
@ C/R > 10
Picture enhancement SmartImage
Display colours 16.7 M
Colour gamut (typical) NTSC 90%*, sRGB 104%*
Scanning Frequency 30–85 kHz (H) / 48–75 Hz (V)
sRGB Yes
Flicker-free Yes
LowBlue Mode Yes
EasyRead Yes
Connectivity
Signal Input VGA (Analogue), DisplayPort 1.2 x 1, HDMI 1.4 x 1, USB-C 3.2 Gen 1 x 1 (upstream, power delivery up to 65 W)
HDCP HDCP 1.4 (DP/HDMI/USB-C)
USB: USB-C 3.2 Gen 1 x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)
Audio (In/Out)
PC audio-in
Headphone out
Sync Input
Separate Sync
Sync on Green
USB
USB-C Reversible plug connector
Super speed Data and Video transfer
DP Built-in Display Port Alt mode
Power delivery USB PD version 3.0
USB-C max. power delivery Up to 65 W (5 V/3 A; 9 V/3 A; 10 V/3 A;12 V/3 A; 15 V/3 A; 20 V/3.25 A)
Convenience
Built-in Speakers 2 W x 2
User convenience
SmartImage
Input
PowerSensor
Menu
Power On/Off
Control software SmartControl
OSD Languages
Brazil Portuguese
Czech
Dutch
English
Finnish
French
German
Greek
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Traditional Chinese
Turkish
Ukrainian
Other convenience
Kensington lock
VESA mount (100 x 100 mm)
Plug and Play Compatibility
DDC/CI
Mac OS X
sRGB
Windows 10 / 8.1 / 8 / 7
Stand
Height adjustment 150 mm
Pivot -/+ 90 degree
Swivel -/+ 175 degree
Tilt -5~30 degree
Power
ECO mode 12.8 W (typ.)
On mode 14.99 W (typ.) (EnergyStar test method)
Standby mode < 0.3 W (typ.)
Off mode Zero watts with Zero switch
Energy Label Class A
Power LED indicator
Operation - White
Standby mode - White (flashing)
Power supply
Built-in
100–240 VAC, 50–60 Hz
Dimensions
Product with stand (max height) 541 x 522 x 216 mm
Product without stand (mm) 541 x 332 x 63 mm
Packaging in mm (W x H x D) 600 x 475 x 198 mm
Weight
Product with stand (kg) 5.19 kg
Product without stand (kg) 3.57 kg
Product with packaging (kg) 6.89 kg
Operating conditions
Temperature range (operation) 0°C to 40°C °C
Temperature range (storage) -20°C to 60°C °C
Relative humidity 20%-80 %
Altitude Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
MTBF (demonstrated) 70,000 hrs (excluded backlight)
Sustainability
Environmental and energy
EnergyStar 8.0
PowerSensor
TCO Certified Edge
WEEE
RoHS
Recyclable packaging material 100 %
Post-consumer recycled plastic 85%
Specific Substances
PVC/BFR free housing
Mercury free
Lead free
Compliance and standards
Regulatory Approvals
CE Mark
FCC Class B
SEMKO
CU-EAC
TUV Ergo
TUV/GS
EPA
ICES-003
UKRAINIAN
CB
Cabinet
Front bezel Black
Rear cover Black
Foot Black
Finish Texture
What's in the box?
Monitor with stand Yes
Cables HDMI cable, DP cable, USB-C to C/A cable, Power cable
User Documentation Yes
