Seasonic PRIME PX-1600 1600W ATX 3.0 Fully-Modular 80+ Platinum PSU
1600W ATX 3.0 fully-modular PSU with 80+ Platinum efficiency, 2x native 16-pin 12VHPWR PCIe 5.0, Japanese caps, digital FDB fan control. Ideal for high-end GPUs/CPUs.
Available in 4–6 business days : 9 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Seasonic PRIME PX-1600 is a premium 1600W ATX 3.0 power supply designed for high-performance gaming and workstation builds. It features full ATX 3.0 and PCIe 5.0 compliance with 2x native 12VHPWR (16-pin) connectors rated at 600W each, perfect for modern GPUs like RTX 4090. Achieving 80 PLUS Platinum certification (92% efficiency at 50% load), it uses 105°C-rated Japanese electrolytic capacitors for reliability and longevity.
Key highlights include Micro Tolerance Load Regulation (MTLR) under 0.5% for stable power delivery, fully modular cabling with PVC embossed sleeves for clean builds, and a 135mm Fluid Dynamic Bearing (FDB) fan with advanced digital hybrid control for silent operation. The cable-free PCB connection enhances output quality. Backed by a 12-year warranty, it’s built for demanding setups with top-tier protection (OVP/OCP/OPP/SCP/UVP).
- ATX 3.0 / PCIe 5.0 ready with 2x 12VHPWR
- 80 PLUS Platinum, 92% efficiency @ 50% load
- Fully modular, 135mm FDB fan, digital control
- Japanese capacitors, MTLR <0.5%
- 12-year warranty, high build quality
| Total power | 1600 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 15 - 10 A |
| Combined power (+3.3V) | 125 W |
| Combined power (+12V) | 1600 W |
| Combined power (+5V) | 125 W |
| Combined power (-12V) | 6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V) | 133.3 A |
| Max output current (+5V) | 25 A |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Peripheral (Molex) power cable length | 690 mm |
| CPU power connector (4+4 pin) | 2x (EPS/ATX12V) |
| CPU power cable length | 70 cm |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.0 |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Number of fans | 1 fan(s) |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 15 - 65% |
| Cables included | CPU, PCIe, Peripheral (Molex), SATA, 2x 12VHPWR (16-pin PCIe 5.0) |
| Safety | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Width | 150 mm |
| Depth | 210 mm |
| Height | 86 mm |
| Warranty | 12 years |
| Fan Bearing Type | Fluid Dynamic Bearing (FDB) |
| Load Regulation | <0.5% (MTLR) |
| PCIe Connectors | 2x 12VHPWR (16-pin, 600W each) + multiple 6+2 pin |
