PCIe to 1x USB C + 1x USB A, USB-Controller
38.00 €
The Delock PCI Express card expands the PC with two external USB 3.2 (Gbit/s) ports. Various USB Type-A devices, such as: B. docking stations, card readers, external housings, etc….
Available to order: 2 piecesOrder today12 NovAt our store24–26 NovDelivered to you26 Nov – 1 Dec
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Delock PCI Express card expands the PC with two external USB 3.2 (Gbit/s) ports. Various USB Type-A devices, such as: B. docking stations, card readers, external housings, etc., can be connected. The card enables a data transfer rate of 10 Gbps on both ports when used simultaneously.
| Typ | USB-Controller |
| EAN | 4043619902996 |
| Manufacturer no. | 90299 |
| Controller Art | USB 3.2 (10 Gbit/s) |
| slot | PCIe x4 |
| Chip | Asmedia ASM3142 |
| Protocol | USB 3.2 Gen 2 (10 Gbit/s) |
| Connections - external | 1x USB A, 1x USB C |
| directly usable devices | 2 |
| Operating System - Supported | Windows 7, Windows 8, Windows 10 |
| Feature | 1 x SATA 15 Pin Power Connector | Backwards compatible with USB 3.0, USB 2.0, USB 1.1 | Power supply via PCI Express interface or via the 4-pin power connector Electrical power per port: USB Type-C: max. 15 watts (5 V / 3 A) USB Type-A: max. 4.5 watts (5 V / 0.9 A) | Supports eXtensible Host Controller Interface (xHCI) specification 1.1 | Supports multiple INs |
| Notice | The USB 3.2 ports (10 Gbit/s) correspond to the former USB 3.1 standard. |
| Weight | 130 Gramm |
