LogiLink PC0090 USB 3.2 Gen 1 PCIe Card - 2x USB-A + 1x USB-C PD
LogiLink PC0090 PCIe expansion card with 2x USB 3.2 Gen 1 Type-A and 1x USB-C PD 3.0 port. Delivers 5 Gbps data transfer and 30W power delivery. Includes low profile bracket.
Available in 2–5 business days : 6 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The LogiLink PC0090 is a PCI Express 2.0 expansion card that adds high-speed USB connectivity to desktop computers. It features two USB 3.2 Gen 1 Type-A ports and one USB 3.2 Gen 1 Type-C port with Power Delivery 3.0 support, enabling up to 5 Gbps data transfer rates and 30W maximum power output for charging compatible devices. The card is powered by both the PCIe bus and an optional ATX 6-pin connector for stable operation.
Designed for easy installation, the PC0090 includes a low-profile bracket for compact cases and supports hot-plug and plug-and-play functionality. It is compatible with Windows 7, 8.x, 10, 11, Windows Server 2008 R2 through 2022, and Linux Kernel 2.6 or later. The card operates reliably across a wide temperature range (0-85°C) and includes built-in protection against over-voltage, over-current, and over-temperature conditions.
Key Features:
- 2x USB 3.2 Gen 1 Type-A ports with 5 Gbps speed
- 1x USB 3.2 Gen 1 Type-C port with USB Power Delivery 3.0 (30W max)
- PCI Express 2.0 1-Lane interface compliance
- Low-profile bracket included for space-constrained builds
- ATX 6-pin power connector for enhanced stability
- Hot-plug and Plug & Play support
- Comprehensive OS compatibility (Windows and Linux)
- Built-in protection circuits (over-voltage, over-current, over-temperature)
| Type | PCI Express Expansion Card |
| Host Interface | PCI Express 2.0 1-Lane (x1) |
| External Ports | 2x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 1 Type-C |
| Data Transfer Rate | 5 Gbps |
| USB Power Delivery | USB-C PD 3.0, 30W max (20V/1.5A) |
| Power Supply | PCIe bus power + ATX 6-pin connector |
| Chipset | VL805 |
| Form Factor | Low Profile |
| Bracket | Low Profile Bracket included |
| Dimensions (Device) | 12 x 10.3 x 2.15 cm |
| Weight (Device) | 60 g |
| Operating Temperature | 0–85°C |
| Operating Humidity | 0–95% RH (no condensation) |
| Protection Features | Over-voltage, over-current, over-temperature protection |
| Hot Plug Support | Yes |
| Plug & Play | Yes |
| Windows Compatibility | Windows 7, 8.x, 10, 11, Windows Server 2008 R2, 2012 R2, 2016, 2019, 2022 (32/64-bit) |
| Linux Compatibility | Linux Kernel 2.6 or later |
| Package Contents | 1x USB 3.2 Gen 1 PCIe Card, 1x Low Profile Bracket, 1x User Manual |
| Packaging Dimensions | 150 x 135 x 30 mm |
| Packaging Weight | 0.11 kg |
