Lian Li SP850 V2 Gold Black 850W SFX PSU ATX 3.1 PCIe5 12V-2x6
Lian Li SP850 V2: 850W SFX PSU, 80+ Gold, ATX 3.1 & PCIe 5 ready w/ native 12V-2×6. Compact 125x100x63.5mm, 92mm FDB fan, zero RPM mode, Japanese caps, fully modular, 10yr warranty.
Available in 10–14 business days : 45 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
High-Performance SFX Power Supply
The Lian Li SP850 V2 is a premium 850W SFX PSU designed for compact SFF builds. It features ATX 3.1 compliance and a native 12V-2×6 connector for PCIe 5.0 GPUs, delivering stable power up to 840W on the 12V rail. With 80 PLUS Gold efficiency (>90% at 50% load), Japanese electrolytic capacitors, and full modularity, it ensures reliability and clean cable management.
Equipped with a 92mm FDB fan supporting zero RPM mode for silent operation under low loads, it maintains low noise even at full power (40dBA max). Comprehensive protections (OCP/OVP/OTP/OPP/SCP/UVP) and a 10-year warranty back its durability for high-end systems.
- ✅ Compact SFX form factor: 125 × 100 × 63.5 mm
- ✅ Fully modular with premium sleeved cables
- ✅ Native 12V-2×6 for next-gen GPUs
- ✅ 92mm FDB fan w/ fanless mode
- ✅ 10-year warranty & Japanese capacitors
| Model | SP850 V2 Gold Black |
| Form Factor | SFX |
| Dimensions (W x H x D) | 125 x 63.5 x 100 mm |
| Max DC Output | 850W |
| Combined +12V | 840W |
| Combined +3.3V & +5V | 100W |
| Efficiency Certification | 80 PLUS Gold |
| ATX Version | ATX 3.1 / PCIe 5.0 |
| Modularity | Fully Modular |
| Fan | 92mm FDB, 3000 RPM max, Fanless Mode (Zero RPM) |
| Noise Level | 40 dBA @ 25°C |
| Input Rating | 100-240Vac 50-60Hz 10-5A |
| PFC | Active PFC >0.90 @ full load 115Vac |
| Protections | OCP / OVP / OTP / OPP / SCP / UVP / SIP / NLP |
| Capacitors | Japanese Electrolytic |
| Warranty | 10 Years |
| PCIe Connectors | 1x 12V-2x6 (16-pin), additional 6+2 pin PCIe |
| EPS Connectors | 2x 4+4 pin |
| Working Temperature | 0-40°C |
