Intel Core i5-13500 - 13th Gen (LGA1700) - 14 Cores/20 Threads, up to 4.8GHz, Intel UHD 770
Intel Core i5-13500 (13th Gen) LGA1700 CPU — 14 cores/20 threads, up to 4.8 GHz, supports DDR4 & DDR5, Intel UHD Graphics 770, PCIe 5.0
Item out of stock
This item is currently out of stock. We can suggest alternatives or try to source it for you. Call us at 22 270068 or email offer@armenius.cy.
Intel Core i5-13500. Processor family: Intel® Core™ i5. Processor socket: LGA 1700. Package type: Box. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR4-SDRAM. DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770. On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1. On-board graphics card base frequency: 300 MHz. Market segment: Desktop. Use conditions: PC/Client/Tablet. Workstation. PCI Express slots version: 5.0. 4.0. Processor package size: 45 x 37.5 mm
| Processor manufacturer | Intel |
| Processor generation | 13th gen Intel® Core™ i5 |
| Processor model | i5-13500 |
| Processor family | Intel® Core™ i5 |
| Processor cores | 14 |
| Processor socket | LGA 1700 |
| Processor threads | 20 |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Efficient cores | 8 |
| Processor boost frequency | 4.8 GHz |
| Performance-core boost frequency | 4.8 GHz |
| Performance-core base frequency | 2.5 GHz |
| Efficient-core boost frequency | 3.5 GHz |
| Efficient-core base frequency | 1.8 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Package type | Box |
| Feature | Intel vPro® Essentials Platform Eligibility |
| Processor base power | 65 W |
| Maximum turbo power | 154 W |
| Bus type | DMI4 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 76.8 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 230580 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM. DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 76.8 GB/s |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1550 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card ID | 0x4680 |
| Discrete graphics card model | Not available |
| Number of execution units | 32 |
| Multi-Format Codec Engines | 2 |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet. Workstation |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 5.0. 4.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4 |
| Supported instruction sets | SSE4.1. SSE4.2. AVX 2.0 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Tjunction | 100 °C |
| Target market | Gaming |
| OpenCL version | 3.0 |
| Launch date | Q1'23 |
| Status | Launched |
| Harmonized System (HS) code | 8542310001 |
| Processor package size | 45 x 37.5 mm |
| L2 cache | 11776 KB |
| Maximum internal memory | 192 GB |
| Graphics output | eDP 1.4b. DP 1.4a. HDMI 2.1 |
