Gigabyte A520M K V2 - AM4 Micro-ATX Motherboard | AMD A520, DDR4 up to 64GB, 1x M.2 PCIe 3.0, HDMI 2.1
AM4 Micro-ATX motherboard with AMD A520 chipset. Supports Ryzen 3000/4000 G-Series/5000/5000 G-Series, Dual Channel DDR4 up to 64GB (5100MHz OC, XMP), 1x PCIe Gen3 x4 M.2, 4x SATA 6Gb/s (RAID 0/1/10), HDMI 2.1 (4K@60Hz), GbE LAN, 8-ch HD Audio, Smart Fan 5.
Available instantly upon confirmation : 1 piece
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Gigabyte A520M K V2 is a reliable Micro-ATX motherboard designed for AMD Ryzen processors on the AM4 socket. It supports Ryzen 3000 Series, 3000 G-Series, 4000 G-Series, 5000 Series, and 5000 G-Series CPUs out of the box with no BIOS update required for most. Featuring the AMD A520 chipset, it delivers essential features for budget gaming and productivity builds, including dual-channel DDR4 memory support up to 64GB at speeds reaching 5100MHz (OC) with Extreme Memory Profile (XMP).
Storage options include one M.2 slot (PCIe 3.0 x4/x2 and SATA, type 2280) for fast NVMe SSDs and four SATA 6Gb/s ports with RAID 0, 1, and 10 support. Connectivity is solid with 4x rear USB 3.2 Gen 1 ports, Gigabit Ethernet LAN with bandwidth management, HDMI 2.1 (4096×2160@60Hz, HDCP 2.3, HDR), and D-Sub (1920×1200@60Hz) for multi-display setups. Audio is handled by an 8-channel HD codec with high-end capacitors, and Smart Fan 5 provides advanced cooling control with hybrid fan headers and multiple temperature sensors.
This board emphasizes durability with GIGABYTE Ultra Durable design, making it ideal for stable, long-term use. It lacks PCIe 4.0 and advanced overclocking but excels in value for entry-level AM4 systems.
- CPU Support: Ryzen 3000/4000G/5000/5000G Series (AM4)
- Memory: 2x DDR4 DIMM, 64GB max, 5100MHz OC
- Storage: 1x M.2 PCIe 3.0, 4x SATA III
- Video: HDMI 2.1 4K, D-Sub
- Expansion: 1x PCIe x16 (Gen3), 1x PCIe x1
| Processor manufacturer | AMD |
| Processor socket | Socket AM4 |
| Compatible processor series | AMD Ryzen 3000 Series, AMD Ryzen 3000 G-Series, AMD Ryzen 4000 G-Series, AMD Ryzen 5000 Series, AMD Ryzen 5000 G-Series |
| Motherboard chipset | AMD A520 |
| Motherboard form factor | micro ATX |
| Supported memory types | DDR4-SDRAM |
| Number of memory slots | 2 |
| Maximum internal memory | 64 GB |
| Supported memory clock speeds | 2133/2400/2667/2933/3200/3400/3466/3600/3733/3866/4000/4133/4266/4400/4600/4800/5100(O.C.) MHz |
| Memory channels | Dual-channel |
| ECC сompatibility | ECC & Non-ECC |
| Number of M.2 (M) slots | 1 |
| Supported storage drive interfaces | M.2, SATA III |
| Number of SATA III connectors | 4 |
| RAID levels | 0, 1, 10 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Maximum resolution | 4096 x 2160 pixels @60Hz |
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet interface type | Gigabit Ethernet |
| Audio output channels | 7.1 channels |
| PCI Express x16 slots | 1 |
| PCI Express x1 slots | 1 |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Width | 233 mm |
| Depth | 198 mm |
| Package width | 265 mm |
| Package depth | 235 mm |
| Package height | 52 mm |
| Package weight | 675 g |
| Country of origin | China |
| Warranty period | 3 year(s) |
