Dahua HDCVI 2.0MP Bullet 3.6mm - HFW1200CL-IL-A-S6 - 2.0MP Bullet 3.6mm

SKU:
Brand: Dahua
Barcode:
28.50 €

Requires XVR firmware upgrade to V4.001.0000004.1.R.220323 or later for Smart Dual Light operation.

Available in 2–3 business days : 5 pieces

For any questions about this item, availability, or delivery times, please contact us at 22 270068

* In order to use the Smart Dual Light HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000004.1.R.220323 or later version.

  • Max. 30 fps@1080p
  • 3D NR
  • Smart Dual Light
  • 20 m illumination distance
  • Super Adapt
  • Built-in mic
  • 3.6 mm fixed lens
  • CVI/CVBS/AHD/TVI switchable.
  • IP67, 12 VDC

Camera

  • Image Sensor : 2 MP CMOS
  • Max. Resolution : 1920 (H) × 1080 (V)
  • Scanning System : Progressive
  • Electronic Shutter Speed : PAL: 1/25 s–1/100000 s / NTSC: 1/30 s–1/100000 s
  • Min. Illumination : 0.01 lux@F2.0 (Color, 30 IRE) / 0.001 lux@F2.0 (B/W, 30 IRE) / 0 lux (Illuminator on)
  • S/N Ratio : >65 dB
  • Illumination Distance : IR: 20 m / Warm light: 20 m
  • Illuminator On/Off Control : Auto
  • Illuminator Number : 2 (Warm light);2 (IR light)

Lens

  • Lens Type : Fixed-focal
  • Auto Focus : No
  • Lens Mount : M12
  • Focal Length : 3.6 mm
  • Max. Aperture : F2.0
  • Field of View : 3.6 mm: H: 83°; V: 48°; D: 105°
  • Iris Control : Fixed
  • Close Focus Distance : 3.6 mm: 0.7 m

Video

  • Video Frame Rate : CVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / AHD:
  • PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / TVI:  PAL: 1080p@25 fps; NTSC: 1080p@30 fps; / CVBS: PAL: 960H; NTSC: 960H
  • Resolution : 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
  • Day/Night : Auto(ICR)/Color/B/W
  • BLC : BLC; HLC; DWDR
  • WDR : DWDR
  • White Balance : Auto Area white balance
  • Gain Control : Auto
  • Noise Reduction : 3D NR
  • Illumination Mode  : Smart IR&WL; WL Mode; IR Mode
  • Mirror : Yes
  • Privacy Masking : Off/On (8 areas, rectangle)

Certification

  • Certifications : CE-LVD: EN 62368-1; / CE-EMC: EN 55032; EN 55035; / FCC: 47 CFR FCC Part 15, Subpart B

Port

  • Video Output : Video output choices of CVI/TVI/AHD/CVBS by one BNC port
  • Audio Input : 1 channel

Power

  • Power Supply : 12 VDC ± 30%
  • Power Consumption : Max 2.6W (12 VDC, IR on)

Environment

  • Operating Temperature : –40 °C to +60 °C
  • Operating Humidity : <95% (RH), non-condensing
  • Storage Temperature : –40 °C to +60 °C
  • Storage Humidity : <95% (RH), non-condensing
  • Protection :IP67

Structure

  • Casing Material : Plastic
  • Product Dimensions : 163.4 mm × 69.7 mm × 70 mm
  • Net Weight : 0.18 kg
  • Gross Weight : 0.26 kg
  • Installation : Wall mount; ceiling mount; vertical pole mount
