Artsound - Arcus-EDS - KNX Interface for Smart Audio products

SKU:
Brand: Artsound
Barcode:
429.00 €

KNX gateway bridging ETS via Ethernet to KNX, with telegram monitoring, logging, real-time graphs, and WebSocket browser visualization.

Available to order: 5 pieces (2–3 business days)Order today20 NovAt our store24–25 NovDelivered to you26–30 Nov

For any questions about this item, availability, or delivery times, please contact us at 22 270068

Questions? Call 22 270068

  • 5 piecesAvailable to order
  • 4–6 business daysdelivered to you
  • 2–3 business daysat our store in Nicosia
  • Pay your waycards, Apple Pay, Google Pay or in store

Product information

Details

The KNX-GW-IP-2TE is used for coupling the ETS ( PC software tool ) via Ethernet to the KNX bus for addressing and programming KNX components.

Using the KNX-group monitor allows for the monitoring and transfer of telegrams via the KNX-bus in real time. The site of the KNX-group monitor is subdivided into a configuration and a telegram section.

The KNX-IP-gateway is able to save telegrams. The KNX-telegram logger lists the saved telegrams. It is possible to set a timeframe as well as a group address filter.

To visualize the data, up to three different group addresses can be displayed in one graph.

The gateway can link html-sites with KNX-files and visualize them in every browser, provided that websockets are supported.

  •  Operating voltage: 9 .. 30VDC max. 1,5W  2-pin terminal with screws
  •  Terminal bus voltage: KNX 2-pin terminal ( red / black )
  •  Power consumption (KNX): Approx. 120mW (at 24V DC)
  •  Ambient temperature: Storage -25 .. +85°C
  •  Operation -25 .. +55°C
  •  Ethernet: 10/100 Mbit/s RJ45
