ARCTIC TP-3 100x100mm 0.5mm Premium Thermal Pad
ARCTIC TP-3 100x100mm 0.5mm silicone thermal pad compresses to 0.3mm, bridges 0.2mm gaps. High conductivity, very soft (55 Shore OO), electrically insulating. Ideal for RAM, chipsets, M.2 in PCs, laptops.
Available in 2–5 business days : 5 pieces
For any questions about this item, availability, or delivery times, please contact us at 22 270068
High Performance — Very Soft
Based on silicone and special filler, TP-3 outperforms standard pads for height variances from tolerances. Offers excellent thermal conductivity with extremely low hardness (55 Shore OO).
Minimize Thermal Resistance & Versatile Use
0.5mm pad compresses to 0.3mm, filling gaps up to 0.2mm. Heat-conducting, vibration-damping, electrically insulating. Cuttable for RAM, chipsets, ICs in PCs, laptops, GPUs, consoles.
Safe, non-adhesive handling bridges uneven surfaces without stressing components.
- Thickness: 0.5 mm (compresses to 0.3 mm)
- Size: 100 x 100 mm
- Thermal Conductivity: 12 W/mK
- Temp Range: -40~150 °C
- Electrically Insulating & Non-Flammable
| Size | 100 x 100 mm |
| Thickness | 0.5 mm |
| Color | Blue |
| Hardness | 55 Shore OO |
| Thermal Conductivity | 12 W/mK |
| Continuous Use Temperature | -40~150 °C |
| Specific Gravity | 3.4 g/cm³ |
| Dielectric Constant @1MHz | 5.19 |
| Volume Resistance | 2.69 x 10^12 Ω-cm |
| Dielectric Strength | 7.6 kV/mm |
| Flammability Rating | V-0 |
