Intel Core i9-14900 LGA1700 Tray 14th Gen 24C/32T up to 5.8GHz UHD 770
Intel Core i9-14900 14th Gen tray CPU: LGA1700, 24 cores (8P+16E), 32 threads, up to 5.8GHz turbo, UHD Graphics 770, DDR4/DDR5, 65W base/219W turbo.
Available in 4–6 business days : 7 τεμάχιο
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The Intel Core i9-14900 is a high-performance 14th Gen Raptor Lake Refresh desktop processor in tray packaging (no retail box or cooler included). It features 24 cores (8 Performance-cores + 16 Efficient-cores) and 32 threads, with max turbo frequency up to 5.8 GHz via Thermal Velocity Boost. Designed for LGA1700 socket motherboards, it supports DDR4 and DDR5 memory up to 192GB dual-channel at 89.6 GB/s bandwidth.
Integrated Intel UHD Graphics 770 enables up to 4 displays with HDMI 2.1, DisplayPort 1.4a, and eDP 1.4b outputs. Ideal for gaming, content creation, and workstations with 36MB Smart Cache, PCIe 5.0/4.0 support (20 lanes), and technologies like Turbo Boost Max 3.0. Base power 65W, max turbo power 219W, Tjunction 100°C. Launched Q1 2024.
- Socket: LGA 1700
- Cores/Threads: 24 (8P+16E)/32
- Max Frequency: 5.8 GHz
- Integrated Graphics: UHD 770 (4 displays)
- Memory: DDR4/DDR5 up to 192GB
- TDP: 65W (219W turbo)
- Packaging: Tray (no cooler)
| Processor manufacturer | Intel |
| Processor generation | Intel® Core™ i9 (14th gen) |
| Processor model | i9-14900 |
| Processor family | Intel® Core™ i9 |
| Processor cores | 24 |
| Processor socket | LGA 1700 |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Performance cores | 8 |
| Efficient cores | 16 |
| Processor boost frequency | 5.8 GHz |
| Performance-core boost frequency | 5.4 GHz |
| Performance-core base frequency | 2 GHz |
| Efficient-core boost frequency | 4.3 GHz |
| Efficient-core base frequency | 1.5 GHz |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 65 W |
| Maximum turbo power | 219 W |
| Processor codename | Raptor Lake |
| Processor ARK ID | 236793 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM, DDR5-SDRAM |
| Memory channels | Dual-channel |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1650 MHz |
| Number of displays supported (on-board graphics) | 4 |
| Market segment | Desktop |
| PCI Express slots version | 4.0, 5.0 |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.6 GHz |
| Intel® Thermal Velocity Boost Frequency | 5.8 GHz |
| Tjunction | 100 °C |
| Launch date | Q1'24 |
| Status | Launched |
