Dahua Alarm Automation Transmitter - ARM320-W2(868) - POE

SKU:
Μάρκα: Dahua
Barcode:
218.50 €

Connects to hub via RF or network; 16 alarm inputs, 4 relay outputs; 2 auxiliary power outputs up to 24W; supports POE, AC power, and rechargeable battery.

Available in 2–3 business days : 5 τεμάχιο

For any questions about this item, availability, or delivery times, please contact us at 22 270068

  • Connection to Hub through RF or network communication.
  • 16 alarm inputs, 4 relay outputs.
  • 2 auxiliary power outputs with a maximum power of 24W for powering wired detector and siren, and support overload and short circuit detection.
  • POE, AC power and rechargeable battery (optional) three power supply options.

Port

  • Alarm Input : Supports local 16-channel alarm input, 1 to 6 channels support pulse detection, and 1 to 16 channels support 0EOL/EOL/2EOL/3EOL
  • Alarm Output : Supports 4 lcoal channels(Max 30 VDC, 3A)
  • Network Mode : Ethernet
  • Network Port : 1 × RJ-45 10/100 Mbps Ethernet port; / PoE power supply
  • Auxiliary Power Output : 2 built-in auxiliary output, 14.5V, total 1 A (PoE), 2 A (Non PoE)

Function

  • Indicator Light : One indicator (indicator status)
  • Button : 1 × switch button, 1 × reset button
  • Remote Update : Supports cloud update
  • Low Battery Detection : Yes
  • Tamper : Yes

Technical

  • LED Indicator : 1 × indicator
  • Scenario : Indoors

Wireless

  • Carrier Frequency : 868 MHz
  • Transmitter Power (EIRP) : limit 25 mW
  • Communication Mechanism : Two-way
  • Communication Distance : RF: Up to 1,600 m (5249.34 ft) in an open space
  • Encryption Mode : AES128
  • Frequency Hopping : Yes

General

  • Power Supply : 100-240 VAC, PoE (802.3at)
  • Power Supply Type : Type A
  • Standby Time : Static standby: Up to 30 hrs
  • Low Battery Threshold : 11,000 mV
  • Battery Restore Threshold : 12,000 mV
  • Power Consumption : 220 VAC quiescent current (40 mA Irms) / 220 VAC max current@2Aload + charge (315 mA Irms) / POE quiescent current (125mA) / POE max current@0.75Aload + charge (612 mA)
  • Operating Temperature : –10 °C to +50 °C (+14 °F to +122 °F)
  • Operating Humidity : 10%–90%
  • Product Dimensions : 304 mm × 235 mm × 90.8 mm (11.97″ × 9.25″ × 3.57″)
  • Net Weight : 1.22 kg (2.69 lb)
  • Gross Weight : 1.78 kg (3.92 lb)
  • Installation : Wall mount
  • Casing Material : PC + ABS
  • Appearance Color : White
  • Protection : IP30
  • Certifications : CE
  • Anti-corrosion Level : Basic Protection
  • Storage Temperature : –10 °C to +55 °C (+14 °F to +131 °F)
  • Storage Humidity : 10%–90%
  • Packaging Dimensions : Standalone packaging: 269 mm × 14 0 mm × 280 mm (10.59″ × 0.55″ × 11.02″) (L × W × H)
  • Protective case packaging: 585 mm × 443 mm × 399 mm (23.03″ × 17.44″ × 15.71″) (L × W × H)
