ASUS ProArt Z890-CREATOR WIFI LGA1851 ATX Motherboard – Thunderbolt 5/4, 192GB DDR5
Professional ATX motherboard for Intel Core Ultra Series 2 (LGA1851) with Z890 chipset, supporting up to 192GB DDR5, dual Thunderbolt 5 & 4, PCIe 5.0, WiFi 7, and 10G/2.5G Ethernet.
Available in 8–10 business days : 1 τεμάχιο
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The ASUS ProArt Z890-CREATOR WIFI is a premium ATX motherboard engineered for professional content creators and high-performance computing. Built on the Intel Z890 chipset and supporting Intel Core Ultra Series 2 processors (Arrow Lake-S) via LGA1851 socket, this board combines robust power delivery with cutting-edge connectivity and storage options.
Featuring dual Thunderbolt 5 ports (80 Gbps each, up to 120 Gbps with Bandwidth Boost) plus one Thunderbolt 4 port, the ProArt Z890-CREATOR WIFI enables seamless connection to high-speed peripherals and supports dual 8K or quad 4K monitor configurations via DisplayPort In. Memory support reaches 192GB DDR5 across four DIMM slots with overclocking up to 9066+MT/s (OC), while storage flexibility includes five M.2 slots (one PCIe 5.0 x4, four PCIe 4.0 x4) and four SATA III ports with full RAID support (0/1/5/10). Networking is handled by dual Ethernet (10G + 2.5G) and WiFi 7 (802.11be) with 320MHz bandwidth support, complemented by Bluetooth 5.4. The robust power design features 16(90A)+1(90A)+2(90A)+2(80A) power stages optimized for high-core-count CPUs, while an eight-layer PCB and premium components ensure stability and longevity. The elegant black finish with gold accents, integrated I/O shield, and DIY-friendly features like M.2 Q-Release and PCIe Q-Release Slim make this board ideal for both creators and enthusiasts.
Additional features include ASUS AI Advisor, AI Overclocking, AI Cooling II, and AI Networking II for intelligent system optimization. The board supports ASUS Control Center Express for remote management, includes three months of Adobe Creative Cloud, and comes with comprehensive software utilities (ASUS DriverHub, GlideX, ProArt Creator Hub) for workflow enhancement.
- Socket: LGA1851 (Intel Core Ultra Series 2)
- Chipset: Intel Z890
- Memory: 4x DDR5 DIMM, up to 192GB, 9066+MT/s (OC)
- Storage: 5x M.2 (1x PCIe 5.0, 4x PCIe 4.0) + 4x SATA III
- Connectivity: 2x Thunderbolt 5, 1x Thunderbolt 4, 10G + 2.5G Ethernet, WiFi 7, Bluetooth 5.4
- Expansion: 2x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4 mode)
- Power: 16+1+2+2 power stages (90A/90A/90A/80A)
- Form Factor: ATX (305 x 244mm)
- Color: Black with gold accents
| Processor Socket | LGA1851 |
| Chipset | Intel Z890 |
| Form Factor | ATX |
| Memory Type | DDR5 SDRAM |
| Memory Slots | 4x DIMM |
| Maximum Memory | 192 GB |
| Memory Speed (OC) | Up to 9066+ MT/s |
| Memory Architecture | Dual-channel |
| Memory Profiles | XMP, AEMP III, DIMM Fit, DIMM Flex |
| M.2 Slots | 5 (1x PCIe 5.0 x4, 4x PCIe 4.0 x4) |
| M.2 Supported Sizes | 2242, 2260, 2280, 22110 |
| SATA III Ports | 4 |
| RAID Support | RAID 0, 1, 5, 10 |
| PCIe Expansion Slots | 2x PCIe 5.0 x16 (x16 or x8/x8), 1x PCIe 4.0 x16 (x4 mode) |
| Thunderbolt Ports | 2x Thunderbolt 5 (80 Gbps each, up to 120 Gbps with Bandwidth Boost), 1x Thunderbolt 4 |
| Ethernet Ports | 2 (10 Gigabit + 2.5 Gigabit) |
| WiFi Standard | WiFi 7 (802.11be), 2x2 configuration, 320 MHz bandwidth, up to 5.8 Gbps |
| WiFi Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Bluetooth | Bluetooth 5.4 |
| Audio Codec | Realtek ALC1220P |
| Audio Channels | 7.1 channels |
| HDMI Ports | 1x HDMI 2.0b (4096 x 2160) |
| DisplayPort | 1x DisplayPort 2.1 In (supports up to 8K@60Hz with DSC) |
| USB 2.0 Headers | 1 |
| USB 3.2 Gen 1 Headers | 1 |
| USB 3.2 Gen 2 Headers | 1 |
| USB 3.2 Gen 2 Type-A Ports | 6 |
| Power Delivery | 16(90A)+1(90A)+2(90A)+2(80A) power stages |
| CPU Fan Headers | 2 |
| Chassis Fan Headers | 5 |
| Water Pump Header | 1 |
| RGB LED Headers | 3 (3-pin 5V ARGB + 4-pin 12V RGB) |
| ATX Power Connector | 24-pin |
| EPS Power Connectors | 2x 8-pin |
| 12V Power Connector | Yes |
| BIOS Type | UEFI AMI |
| BIOS Memory | 256 Mbit |
| BIOS Features | EZ Flash, OC Profiles, DIMM Fit, AEMP III, AI Overclocking, AI Cooling II, AI Networking II |
| PCB Layers | 8-layer |
| Motherboard Dimensions | 305 x 244 mm (12.0 x 9.6 in) |
| Motherboard Weight | 1.97 kg (4.3 lbs) |
| Color | Black with gold accents |
| Integrated I/O Shield | Yes |
| Clear CMOS Button | Yes |
| SafeSlot Retention Brackets | Yes (PCIe x16 slots) |
| Q-Release Slim | Yes (top PCIe x16 slot) |
| M.2 Q-Release | Yes |
| M.2 Q-Slide | Yes |
| M.2 Q-Latch | Yes |
| Q-Antenna | Yes (WiFi antenna connectors) |
| Supported Operating Systems | Windows 11, Linux |
| Included Accessories | SATA cables, WiFi antennas, I/O shield, documentation, driver CD/USB |
| Software Included | ProArt Creator Hub, ASUS Control Center Express, ASUS DriverHub, ASUS GlideX, 3 months Adobe Creative Cloud |
