ASUS Pro B760M-C-CSM LGA1700 Micro-ATX DDR5 Motherboard Intel B760
Micro-ATX Intel B760 LGA1700 motherboard for business PCs. Supports DDR5 up to 128GB (4xDIMM, XMP), PCIe4.0 x16, 2x M.2 PCIe4.0, 4x SATA RAID, VGA/HDMI/2xDP, GbE LAN, TPM, 7.1 audio.
Available in 2–3 business days : 5 τεμάχιο
For any questions about this item, availability, or delivery times, please contact us at 22 270068
The ASUS Pro B760M-C-CSM is a reliable Micro-ATX motherboard designed for business and professional environments, featuring Intel B760 chipset and LGA1700 socket for 12th/13th/14th Gen Intel Core processors, Pentium Gold, and Celeron.
It supports dual-channel DDR5 memory up to 128GB across 4 DIMM slots with XMP profiles and speeds up to 6200MHz (OC). Storage options include 2x M.2 slots (PCIe 4.0 x4, 2242/2260/2280) and 4x SATA 6Gb/s ports with RAID 0/1/5/10. Expansion features PCIe 4.0 x16 graphics slot and 2x PCIe 3.0 x1 slots. Connectivity comprises Intel Gigabit Ethernet, Realtek ALC897 7.1 audio, and rear I/O with VGA, HDMI 2.1, 2x DisplayPort 1.4, 2x USB 3.2 Gen1 Type-A, 2x USB 2.0.
Business-oriented features enhance security and manageability: onboard TPM, self-recovering BIOS, COM debug header, Q-LED diagnostics, ASUS Management Suite, and anti-moisture/ESD protection for durability.
- CPU: LGA1700 (12th-14th Gen Intel)
- Memory: 4x DDR5, max 128GB
- Storage: 2x M.2 PCIe4.0, 4x SATA
- Video: VGA + HDMI 2.1 + 2x DP 1.4
- LAN: 1x Gigabit Ethernet
- Form Factor: Micro-ATX
| Processor manufacturer | Intel |
| Processor socket | LGA 1700 |
| Compatible processor series | Intel® Celeron®. Intel® Core™ i3. Intel® Core™ i5. Intel® Core™ i7. Intel® Core™ i9. Intel® Pentium®. Intel® Pentium® Gold |
| Motherboard chipset | Intel B760 |
| Motherboard form factor | micro ATX |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Maximum internal memory | 128 GB |
| Supported storage drive interfaces | M.2, SATA III |
| Number of storage drives supported | 6 |
| RAID levels | 0, 1, 5, 10 |
| Number of SATA III connectors | 4 |
| Number of M.2 (M) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet interface type | Gigabit Ethernet |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| Audio output channels | 7.1 channels |
| Windows operating systems supported | Windows 10, Windows 11 |
| Width | 244 mm |
| Depth | 244 mm |
| BIOS memory size | 128 Mbit |
| Cables included | SATA |
